General Information

Product Type : Ethernet Switch Manufacturer Part Number : EZNET-16SW Manufacturer Website Address : www.smc.com Marketing Information : This 16 Port EZ Switch provides the power of switching with the ease of use and affordability of traditional shared hubs. Truly Plug-and-Play, the EZNET-16SW automatically learns about the devices on your network and configures itself, avoiding complicated setup procedures. Dramatic improvements in performance can easily be seen, with speeds of up to 200Mbps per port. Since full bandwidth capability is achieved on each individual port, the congestion problems of shared hubs are easily avoided. Manufacturer : SMC Networks, Inc Product Name : EZ Switch EZNET-16SW Product Line : EZ Switch

Interfaces/Ports

Interfaces/Ports : 16 x 10/100Base-TX Interfaces/Ports Details : 15 x RJ-45 10/100Base-TX Auto-sensing/Auto-negotiating 1 x RJ-45 10/100Base-TX Auto-sensing/Auto-negotiating Uplink

Media & Performance

Data Transfer Rate : 10Mbps Ethernet 100Mbps Fast Ethernet Connectivity Media : Category 4 UTP 10Base-T Category 5 UTP 10/100Base-TX Category 3 UTP 10Base-T Performance : 3.2Gbps Bandwidth

Network & Communication

Address Table : 2K MAC Addresses Layer Support : 2 Switching Switching Method : Store-and-forward Flow Control : Back Pressure (Half-duplex) IEEE 802.3x (Full-duplex)

Memory

Memory : 128KB Buffer Memory

Controls/Indicators

Status Indicators : Power Link/Activity 100 Mbps Full Duplex

Power Description

Input Voltage : 100 V AC to 240 V AC Frequency : 50 Hz or 60 Hz Input Current : 0.18 A @ 110V AC Maximum 0.12 A @ 240V AC Maximum Power Consumption : 27 W Maximum

Environmental Conditions

Humidity : 5% to 95% Non-condensing Operating Temperature : 0 °C to 40 °C Operating -31.67 °C to 70 °C Storage Thermal Dissipation : 92 BTU/h Maximum

Physical Characteristics

Dimensions : 4.32cm Height x 33.02cm Width x 20.32cm Depth Shipping Dimensions : 8.25cm Height x 27.94cm Width x 32.39cm Depth Shipping Weight : 2.65 kg Weight : 2.1 kg Color : Black Form Factor : Rack-mountable

Miscellaneous

Additional Information : Filtering and Forwarding at full wire speed on all ports Plug-and-Play capability eliminates complicated setup procedures Address Learning feature probes your network and auto-configures the switch Uplink port included for easy connection to additional switches Package Contents : EZNET-16SW Ethernet Switch Rackmount Kit Certifications & Standards : ISO/IEC 8802-3 Ethernet IEEE: IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3x flow control EMC/Safety Compliance: CE Mark Emissions FCC Class A VCCI Class A Industry Canada Class A EN55022 (CISPR 22) Class A C-Tick - AS/NZS 3548 (1995) Class A Immunity: IEC 1000-4-2/3/4/6 Safety: CSA/NRTL (CSA 22.2 No. 950 & UL 1950) EN60950 (TÜV/GS)

Warranty

Standard Warranty : 3 Year(s)
